| DESCRIPTION | FINISHES | AISI | WNr | SIZE | C.I.D | COIL Wt. | U.T.S | ||
|---|---|---|---|---|---|---|---|---|---|
| MM | MM | Kgs | N/Sqmm | Kgs /Sqmm | Ksi | ||||
| Soft Annealed | Bright | 201 / 201M | - | 0.90 - 1.90 | 300 | 50 - 100 | 750 - 850 | 76 - 86 | 108 - 124 |
| 204Cu / 202 | 2.00 - 6.00 | 500 | 100 - 200 | 700 - 800 | 72 - 82 | 103 - 117 | |||
| 1/4 Hard | Bright | 201 / 201M | - | 0.90 - 1.90 | 300 | 50 - 100 | 850 - 1100 | 86 - 112 | 122 - 160 |
| 1/2 Hard | 204Cu / 202 | 2.00 - 6.00 | 500 | 100 - 200 | |||||
| Soft Annealed | Matt / Bright | 304 / 316 | 4301 / 4401 | 0.90 - 1.90 | 300 | 50 - 100 | 650 - 750 | 66 - 76 | 94 - 108 |
| 304L / 316L | 4306 / 4404 | 2.00 - 6.00 | 500 | 100 - 200 | 600 - 700 | 62 - 72 | 88 - 103 | ||
| 1/4 Hard | Bright | 304 / 316 | 4301 / 4401 | 0.90 - 1.90 | 300 | 50 - 100 | 750-850 | 76-86 | 108 - 124 |
| 303 / 316Ti | 4305 / 4571 | 2.00 - 6.00 | 500 | 100 - 200 | 700-800 | 72-82 | 103 - 117 | ||
| 1/2 Hard | Matt / Bright | 304 | 4301 | 0.90 - 1.90 | 300 | 50 - 100 | 1030 - 1230 | 105 - 126 | 150 - 180 |
| 316 | 4401 | 2.00 - 4.00 | 500 | 200 - 300 | |||||
| 3/4 Hard | Matt Coated | 304 | 4301 | 0.90 - 1.90 | 300 | 50 - 100 | 1400 - 1600 | 142- 162 | 203 - 231 |
| 316 | 4401 | 2.00 - 3.00 | 500 | 200 - 300 | |||||
| Spring Hard | Matt | 304 / 316 | 4301 / 4401 | 0.90 - 1.90 | 300 | 50 - 100 | AS PER ASTM A313 DIN 17224 | ||
| Coated | 302 | 4310 | 2.00 - 3.00 | 500 | 200 - 300 | ||||
